Polynomial Chaos Expansion (PCE) for Uncertainty Quantification

If the input dimension is low—roughly 5 to 10 or fewer—it's overwhelmingly more efficient. For example, consider a car crash analysis where the Young's modulus of the material, plate thickness, and friction coefficient are treated as three uncertain parameters. With the Monte Carlo method, you'd need to run the FEM about 10,000 times to stabilize the statistics. But with PCE, you can achieve equal or better accuracy with only 50 to 100 FEM runs.

The key idea is "approximating the response surface with polynomials." We represent the uncertainty of the input parameters as random variables $\boldsymbol{\xi}$ and expand the output quantity $Y$ as a linear combination of orthogonal polynomials like Hermite or Legendre. Once this approximation (surrogate model) is built, we can compute the mean, variance, probability density function, and sensitivity indices analytically from it. No additional simulations are needed.

Exactly. However, there are caveats. When the number of input parameters exceeds 20, the number of polynomial terms explodes and efficiency drops. This is called the "curse of dimensionality." We'll discuss this in detail later, but to overcome this weakness, sparse PCE and adaptive methods are being researched.

This is actually a crucial point related to the foundation of PCE. The optimal orthogonal polynomial family is determined according to the probability distribution of the input variable—this is called the "Wiener-Askey correspondence."

Convergence slows down, or in the worst case, it diverges. For example, using Hermite polynomials for a uniform distribution input might require 10th order or more for a problem that would normally be sufficient with 3rd order. In practice, we combine appropriate polynomials for each parameter via tensor products, like "Hermite for Young's modulus because it's normally distributed" and "Legendre for plate thickness tolerance because it's uniformly distributed."

The PCE expansion for an output $Y$ with respect to $d$ random variables $\boldsymbol{\xi} = (\xi_1, \ldots, \xi_d)$ is as follows:

Here, the meaning of each symbol is:

• $c_{\boldsymbol{\alpha}}$ — PCE coefficients (the unknowns we want to find)
• $\Psi_{\boldsymbol{\alpha}}(\boldsymbol{\xi})$ — Multivariate orthogonal polynomial basis
• $\boldsymbol{\alpha} = (\alpha_1, \ldots, \alpha_d)$ — Multi-index (polynomial degree for each variable)
• $\mathcal{A}$ — Index set after truncation

They are constructed as the tensor product of univariate orthogonal polynomials for each variable:

For example, if $d=2$, $\xi_1$ is normally distributed (→Hermite $He_k$), and $\xi_2$ is uniformly distributed (→Legendre $P_l$), then $\Psi_{(2,1)}(\boldsymbol{\xi}) = He_2(\xi_1) \cdot P_1(\xi_2)$. Orthogonality means the inner product is zero:

Exactly right. Thinking of the analogy with Fourier series makes it easier to understand. Fourier series expands periodic functions with trigonometric functions (orthogonal basis). PCE expands stochastic responses with orthogonal polynomials. The principle is exactly the same.

This is the most beautiful part of PCE. Thanks to orthogonality, statistics can be obtained directly from the coefficients:

Furthermore, skewness, kurtosis, and even the probability density function can be obtained analytically. For example, to get the probability density function, you apply Monte Carlo sampling to the PCE approximation $Y(\boldsymbol{\xi})$, but this is polynomial evaluation, not FEM, so it finishes in an instant. Even 100,000 samples are on the order of milliseconds.

This is arguably PCE's killer feature. Sobol sensitivity indices can be calculated directly from the PCE coefficients. The first-order Sobol index for the $i$-th variable is:

Here, $\mathcal{A}_i$ is the set of "terms that depend only on $\xi_i$" (i.e., $\alpha_j = 0 \; \forall j \neq i$ and $\alpha_i > 0$). The total Sobol index $S_i^T$ is similarly obtained from the coefficients of "all terms involving $\xi_i$."

Good question. For example, in predicting residual stress in a weld, let's say the input parameters are heat input $Q$, welding speed $v$, and preheat temperature $T_0$. After performing PCE expansion and obtaining the coefficients, if the results are $S_Q = 0.65$, $S_v = 0.22$, $S_{T_0} = 0.08$, then you know that 65% of the variation in residual stress is due to uncertainty in heat input. This directly leads to design decisions like "heat input management should be the top priority."

There are two main methods. First, let's explain the Galerkin projection method (intrusive PCE). Using orthogonality, the PCE coefficients $c_{\boldsymbol{\alpha}}$ are found via inner product:

Sharp observation. In the Galerkin projection method, you need to substitute the PCE expansion into the governing equations and modify the solver itself. For example, for the structural analysis stiffness equation $[K(\boldsymbol{\xi})]\{u(\boldsymbol{\xi})\} = \{F(\boldsymbol{\xi})\}$, you expand $K$, $u$, and $F$ with PCE and derive a system of equations via projection onto each basis. Theoretically, this is the most accurate, but it requires rewriting the internals of existing FEM solvers, making it difficult to use in practice. This is why it's called "intrusive."

Yes, there is. The overwhelmingly used method in practice is Non-Intrusive PCE. It treats existing FEM solvers as black boxes. The procedure is:

1. Generate $N$ sample points $\{\boldsymbol{\xi}^{(1)}, \ldots, \boldsymbol{\xi}^{(N)}\}$
2. Run FEM at each sample point and obtain outputs $\{Y^{(1)}, \ldots, Y^{(N)}\}$
3. Estimate coefficients via least squares

In matrix form, it's $\hat{\mathbf{c}} = (\boldsymbol{\Psi}^T \boldsymbol{\Psi})^{-1} \boldsymbol{\Psi}^T \mathbf{Y}$. Here, $\boldsymbol{\Psi}$ is the $N \times P$ design matrix ($\Psi_{k,\boldsymbol{\alpha}} = \Psi_{\boldsymbol{\alpha}}(\boldsymbol{\xi}^{(k)})$). This works with any solver output, whether it's Abaqus, Ansys, or OpenFOAM.

The minimum condition is $N \geq P$ (samples greater than or equal to the number of terms), but in practice, an oversampling ratio of 2 to 3 times is recommended. That is, $N = 2P \sim 3P$. For example, if $d=5$, $p=3$, then $P=56$ terms, so $N = 112 \sim 168$ FEM runs are needed.

Good question. The choice of sample points (design of experiments) directly affects PCE accuracy. Let's compare the main methods:
