Cryogenic Thermal Analysis (Heat Leak into Vacuum-Insulated Tanks)

Category: Thermal–Fluid Coupling | Revised 2026-10-01
CAE visualization for cryogenic thermal theory - technical simulation diagram
Cryogenic Thermal-Fluid Analysis

Theory: three heat-leak paths

Overview

🙋

I'm designing a liquid nitrogen tank. Can I estimate how much boils off per day beforehand?

🎓

Yes. A cryogenic tank evacuates the space between inner and outer vessels to minimise incoming heat. Heat still arrives three ways: radiation from the outer vessel, conduction through the neck and supports, and residual gas conduction if the vacuum is poor. All of it goes into evaporating liquid, so heat leak divided by latent heat gives the boil-off. Cryogenic pitfalls are that conductivity changes greatly with temperature, and that liquid hydrogen has little latent heat.

Radiation and boil-off

$$ q = \frac{\sigma\left(T_h^4 - T_c^4\right)}{(N+1)\left(\frac{2}{\varepsilon} - 1\right)}, \qquad \dot m = \frac{Q}{h_{fg}} $$

$\varepsilon$ is the emissivity of both surfaces (taken equal) and $N$ the number of floating radiation shields between them; each shield cuts radiation to $1/(N+1)$. $h_{fg}$ is latent heat.

Temperature-dependent conduction

$$ Q = \frac{A}{L}\int_{T_c}^{T_h} k(T)\,dT $$

Because $k$ varies strongly with temperature, integrate it over temperature rather than using a constant. These conductivity integrals are tabulated per material and are independent of geometry.

Coffee Break Trivia

The vacuum flask came from cryogenics

The household vacuum flask began as a cryogenics research tool. In 1892 the British chemist Dewar built a double-walled glass vessel with a vacuum between the walls and silvered inner surfaces to store liquefied gases. The vacuum stopped conduction and convection and the silver mirror reduced radiation — the same principle as today's vacuum-insulated tanks. Using it, Dewar first liquefied hydrogen in 1898, which is why cryogenic vessels are still called 'dewars'.

Worked example: a 1 m³ spherical tank

A 1 m³ spherical inner vessel (radius 0.62 m, area 4.84 m²) is held in vacuum inside a 300 K outer vessel. With emissivity 0.05 on both surfaces, radiative heat leak was calculated for various shield counts:

Radiation shieldsHeat fluxHeat leak (LN2, 77 K)Heat leak (LH2, 20 K)
None11.7 W/m²56.7 W57.0 W
10 (ideal)1.07 W/m²5.15 W5.18 W
30 (ideal)0.38 W/m²1.83 W1.84 W
Typical real MLI0.5–1 W/m²2.4–4.8 W—

Radiation barely differs between a 77 K and a 20 K cold side: it scales with the fourth power of temperature, so the 300 K outer vessel dominates. Real multilayer insulation, with layer contact, seams and pipe penetrations, is typically several times worse than the ideal calculation.

Boil-off

Heat leakLiquid nitrogenLiquid hydrogen
1 W0.43 kg/day (0.05%/day)0.19 kg/day (0.27%/day)
5 W2.17 kg/day (0.27%/day)0.97 kg/day (1.37%/day)
10 W4.34 kg/day (0.54%/day)1.94 kg/day (2.74%/day)
🙋

Liquid hydrogen loses five times as much for the same heat leak.

🎓

Right. Per mass, liquid hydrogen's latent heat is more than twice nitrogen's, but its density is only one eleventh, so per volume it's about one fifth. Radiation leak is the same, yet the tank contents deplete five times faster. That's why LH2 tanks add a liquid-nitrogen-cooled shield or use boil-off vapour to cool the neck, cutting heat leak by another order of magnitude.

Example 2: neck tube conduction

Heat leak through a stainless steel 304 neck tube (OD 50 mm, wall 0.5 mm, length 0.3 m) was computed. Conductivity is 15.3 W/mK at 300 K, 11.2 at 150 K, 7.9 at 77 K and 2.2 at 20 K.

Cold endConductivity integralHeat leak (variable k)Constant room-temperature kOverestimate
77 K2,705 W/m0.71 W0.89 W26%
20 K3,012 W/m0.79 W1.12 W42%

Analysis workflow

  1. List heat-leak paths: radiation, conduction through supports and piping, residual gas.
  2. Estimate radiation from measured MLI performance, not the ideal calculation.
  3. Compute conduction with conductivity integrals, and consider vapour cooling of the neck.
  4. From total heat leak, derive boil-off and holding time, and check pressure rise if the vessel is closed.
  5. Where needed, analyse thermal stratification and flow instability from boiling in lines.
Coffee Break Trivia

“It boils off three times the calculation”

A newly built liquid nitrogen tank boiled off nearly three times the design calculation. Radiation had been estimated from ideal MLI theory, but around pipe penetrations the insulation was compressed and layers touched. Neck conduction had been computed with room-temperature conductivity — an overestimate — which masked the cause. Estimate MLI from measured values and settle installation details (penetrations, seams) at the drawing stage.

Common mistakes

Mistakes and fixes

MistakeEffectFix
Ideal MLI calculationHeat leak underestimatedMeasured-based values
Constant conductivityConduction badly offUse integrals
Treating LH2 like LN2About 5× boil-offCompare volumetric latent heat
Ignoring vacuum levelGas conduction addedAllow for vacuum degradation
Omitting penetrationsLocal heat leaks missedCount pipes and wiring individually
🙋
