Gear Ratio Calculator & Visualizer

Change tooth counts and efficiency, then compare speed and torque.

Teeth and rotation directionInput ↻
Pitch circles proportional to tooth count. Arrows show rotation direction.Sketch without tooth profiles. Each compound stage is shown on its own axial plane.↻↺Stage 1: Z1=20 → Z2=40

Pitch-circle sketch, tooth profiles omitted / slow motion

Output speed

750rpm

Output torque (assumed efficiency)

19.6N·m

Reverse direction ↺ · 0.5× the input speed. Overall efficiency 98%.

teeth

Slow observation view · 0.000 s

Input, stages and other settings

The train ratio is the product of stage ratios. Each added stage reverses the direction.

1-stage external gear train. Each driven shaft feeds the next stage’s driver shaft.

Stage 1

teeth
rpm
N·m
mm

m changes the real pitch-circle size. The drawing auto-scales, so speed and torque do not change.

Detailed results
Gear ratio i (input speed / output speed)
2
Ideal output torque without loss
20 N·m
Assumed overall efficiency
98%
Input power P_in (the original page’s P)
1,570.796 W
Output power P_out
1,539.38 W
Power loss from the assumption
31.416 W
Pitch diameter of the final driven gear
80 mm
Signed output speed (input positive)
-750 rpm
Signed output torque (positive along output rotation, delivered to the output shaft)
-19.6 N·m

Same-module pitch circles. Tooth profile, undercut, interference and strength are unchecked.

Initial example: 20 → 40 teeth, input 1500 rpm · 10 N·m, efficiency 0.98. If the controls cannot load, this example and the formulas below stay readable.

View, playback, share and compare

Circles are pitch circles and arrows show rotation direction. They do not show force distribution or tooth strength. Each compound stage is drawn on its own plane and auto-scaled.

With a mouse or pen, drag a gear in the drawing up or down to change teeth. Focus the drawing and use ↑↓ to adjust the output-side teeth. On touch screens the drawing scrolls the page, so change teeth with the input fields.

The multiplier only affects the observation clock. Displayed rpm and torque do not change.

0/5 saved

What the calculation means and where it applies

One external pair: i = Z₂/Z₁, n₂ = −n₁/i. For compound trains, i is the product of stage ratios and the sign is (−1)^stages. Gears on the same intermediate shaft share speed. As on the original page, the simple/compound choice and the stage count are independent.

Planetary (ring fixed): i = 1 + Z_R/Z_S, carrier speed = n₁/i. Required planet teeth = (Z_R−Z_S)/2. If that is not a positive integer, no layout is drawn and the result is labeled formula-only. A valid layout is still not a check of tooth profile, interference or assembly.

Lossless output torque = T₁ i. With assumed efficiency, T_out = T₁ i η^N (planetary uses N=1 as in the original model). Changing η does not change the geometric speed. Input power P_in = T₁·2πn₁/60, P_out = T_out·2π|n_out|/60 = P_in η^N. Loss is non-negative.

Torque is shown as a magnitude. Signs of external loads and reactions on the shafts and the tooth load distribution are not calculated. Acceleration, elasticity, detailed friction, bearings, temperature and strength are out of scope. This is a kinematic model for comparing motor and machine speed/torque.

Mechanical Engineering

Set tooth counts, input speed, torque, and efficiency to calculate gear ratio and output parameters in real time. Visualize meshing animation and rotation direction for spur, compound, and planetary gears.

Theory & Key Formulas

Simple two-gear pair:$i = Z_2/Z_1 = n_1/n_2$

$T_2 = T_1 \cdot i \cdot \eta$ (η:transmission efficiency)

Compound gear train:$i_{total}= \prod_{k=1}^{n}i_k = \prod_{k=1}^{n}\dfrac{Z_{2k}}{Z_{1k}}$

Planetary gear (ring fixed):$i = 1 + Z_R/Z_S$

Pitch circle diameter:$d = m \cdot Z$ (m: module [mm])

Transmitted power:$P = T_1 \cdot \omega_1 = T_1 \cdot 2\pi n_1/60$

What is Gear Ratio?

🙋
What exactly is a gear ratio, and why does it matter in this simulator?
🎓
Basically, the gear ratio tells you the relationship between the speeds and torques of two connected gears. In this tool, for a simple two-gear system, it's the ratio of the driven gear's teeth to the driving gear's teeth. For instance, if a small gear with 10 teeth drives a large gear with 30 teeth, the ratio is 3:1. Try moving the "Driving gear teeth Z" and "Driven gear teeth Z" sliders above to see the ratio and the animation change instantly.
🙋
Wait, really? So if the ratio is 3:1, does that mean the big gear is three times slower? What happens to the force or turning power?
🎓
Exactly right! Speed and torque have a trade-off. If the output gear is three times slower ($n_2 = n_1 / 3$), its output torque is roughly three times higher ($T_2 \approx T_1 \times 3$). This is how a car's transmission lets the engine turn fast with low torque, but the wheels turn slower with high torque to move the car. In practice, some power is lost to friction. That's what the "Transmission Efficiency η" slider controls-try reducing it from 100% and watch the output torque drop.
🙋
That makes sense for two gears. But the simulator also shows "Planetary" systems. What's going on there with the sun and ring gears? It looks complicated!
🎓
Planetary gear sets are fascinating! They pack a huge speed reduction into a very compact space, which is why they're used in automatic transmissions and robot joints. In this simulator, you control the teeth of the central "sun gear" (Sun Gear) and the outer "Ring Gear Teeth". The ratio depends on which part is driving, which is held, and which is the output. A common case is holding the ring gear: then the speed ratio is $1 + Z_R/Z_S$. Try setting $Z_S=20$ and $Z_R=60$-you'll get a 4:1 reduction in a single, compact stage!

Physical Model & Key Equations

The fundamental relationship for a simple two-gear pair relates the number of teeth (Z) to the rotational speed (n). The gear ratio (i) defines the speed reduction or increase.

$$i = \frac{Z_2}{Z_1}= \frac{n_1}{n_2}$$

Where:
$i$ = Gear Ratio (Driven / Driving)
$Z_1, Z_2$ = Number of teeth on the driving and driven gears
$n_1, n_2$ = Rotational speed of the driving and driven gears (e.g., RPM)

This change in speed directly affects the torque (T), which is the rotational force. Accounting for real-world power loss through efficiency (η) is crucial for accurate design.

$$T_2 = T_1 \cdot i \cdot \eta$$

Where:
$T_1, T_2$ = Input and output torque (e.g., Nm)
$\eta$ = Transmission efficiency per stage (a value between 0 and 1)
Physical Meaning: This equation embodies the conservation of energy (minus losses). Reducing speed ($i \gt 1$) multiplies the available torque, which is the core principle behind gear reducers in machinery.

Frequently Asked Questions

The unit for input rotation speed is rpm (revolutions per minute), and the unit for torque is Nm (Newton meters). In this tool the per-stage efficiency η can be set between 0.9 and 1.0 (default 0.98). For general spur gears, a guideline is 0.95 to 0.98, and for helical gears, 0.97 to 0.99. In a compound train η is applied once per stage.
When the gear ratio is increased, the output rotation speed decreases inversely. For example, if the gear ratio is 2 and the input rotation speed is 1000 rpm, the output will be 500 rpm. In return, the output torque increases approximately twofold, considering efficiency.
In the meshing of external gears, the rotation direction of the driving gear and the driven gear is always opposite. The animation correctly visualizes this physical phenomenon. If you want the rotation direction to be the same, add an idler gear or use an internal gear.
The overall gear ratio of a compound gear train is calculated by multiplying the gear ratios of each stage. For example, if the first stage has a ratio of 2 and the second stage has a ratio of 3, the overall gear ratio is 2 × 3 = 6. In this tool, it is automatically calculated by setting the parameters for each stage individually.

Real-World Applications

Vehicle Transmissions: Gearboxes use multiple gear ratios to allow an engine to operate at efficient speeds while providing the right amount of torque for acceleration (low gear) or high-speed cruising (high gear). The compound gear train relations used in this simulator are the same ones applied when sizing the ratio steps of such a gearbox.

Industrial Reducers & Gearmotors: Conveyor belts, mixers, and heavy machinery use gear reducers to convert the high speed of an electric motor into the low-speed, high-torque motion needed for work. The torque and efficiency relations shown here are the starting point for matching a motor to a gearbox.

Robotics & Precision Actuators: Robotic joints and CNC machine axes require precise control of speed and torque. Planetary gearheads, which you can model here, are favored for their high torque density, low backlash, and compactness, fitting directly into the arm of an industrial robot.

CAE Simulation Input: Before running a multibody dynamics simulation of a drivetrain, the gear ratio and the expected output speed and torque of each stage must be defined. Checking them here first helps catch mistakes in the constraint and load settings of the model early (this tool does not compute inertia properties).

Common Misunderstandings and Points to Note

When you start using this tool, there are a few common pitfalls to watch out for. First, understand that a larger gear ratio does not always mean better performance. While a large reduction ratio amplifies torque, it also significantly reduces rotational speed. For example, if you transmit a motor's maximum speed of 3000 rpm through a mechanism with a gear ratio of 10, the output will be only 300 rpm. This can sometimes be too slow for your intended application. The first step in design is to determine the gear ratio by considering the balance between speed and torque.

Next, be aware that the theoretical torque differs from the actual torque produced. If you set the "Transmission Efficiency η" to 1.0 (ideal) in the tool, the torque doubles neatly, but reality is not so forgiving. Especially in compound gear trains, the efficiency (e.g., 0.98) multiplies at each stage, causing the overall efficiency to drop progressively. With three stages, 0.98 cubed is approximately 0.94. So, with a 100 Nm input, you'd get about 752 Nm instead of the theoretical 800 Nm. Ignoring these losses can lead to major mistakes in motor selection, so be careful.

Also, did you know that in planetary gear parameter settings, the "number of planet gear teeth" is not directly involved in the gear ratio calculation? In the tool, you only input the number of sun gear and ring gear teeth. The number of planet gear teeth is determined by the meshing condition (ensuring all gears fit together smoothly). For instance, with a 20-tooth sun gear and a 60-tooth ring gear, the condition for the planet gear teeth is $(60-20)/2 = 20$ teeth. If you don't check this "assemblability," you might face significant rework at the drawing stage, so keep this in mind.

How to Use

  1. Set the driving gear teeth Z₁ and driven gear teeth Z₂ (6–200 each) with the sliders or number fields. The defaults Z₁=20, Z₂=40 give a gear ratio i=2.000. The stage buttons (1–4 stages) switch to a compound train with teeth for each stage
  2. Set the input speed n₁ (10–6000 rpm), input torque T₁ (0.1–500 N·m), per-stage efficiency η (0.9–1.0) and module m (0.5–20 mm)
  3. There is no Calculate button: every change immediately updates the result cards – gear ratio i, output speed n₂=n₁/i, output torque T₂=T₁·i·η^(stages), transmitted power P=T₁·2πn₁/60 (input-side power, losses not included) and output pitch diameter d₂=m·Z₂ – and the meshing animation

Worked Example

A small motor drives a single-stage reduction: pinion with 20 teeth, driven gear with 60 teeth, input speed 1500 rpm, input torque 10 N·m. Gear ratio i = 60/20 = 3.000. Output speed = 1500/3 = 500.0 rpm. Output torque with the default efficiency η = 0.98 is T₂ = 10 × 3 × 0.98 = 29.40 N·m (30 N·m at η = 1.0). Transmitted power shown by the tool is the input power P = 10 × 2π × 1500/60 = 1570.8 W. For module m = 2 mm, output pitch diameter d₂ = 60 × 2 = 120.0 mm. Enter these values above and the result cards show the same numbers.

Practical Notes

  1. For compound gear trains, cascade multiple stages—each driven gear becomes the next pinion; multiply individual ratios for total reduction
  2. The power card shows input power T₁·ω₁ only; output power is P·η^(stages). Check that the input power is within the motor rating, and use the per-stage efficiency guideline from the FAQ (about 0.95–0.99 for spur and helical gears) rather than treating η = 1.0 as realistic
  3. Module selection (m = 1, 1.5, 2, 2.5 mm) determines tooth size; larger modules carry higher loads but increase overall diameter
  4. Planetary gear systems achieve high ratios in compact space; in the planetary mode the tool uses the ring-fixed case i = 1 + Z_R/Z_S and shows the planet tooth count (Z_R − Z_S)/2 in the drawing
